Wyvern Sonata 236
The Wyvern Sonata is a firm favourite and a popular choice for small to medium size churches and with home organists alike.
Tonal quality with each rank
This latest Sonata builds upon this tradition but takes the tonal quality of this popular organ to new heights. It now has a specification of 36 speaking stops voiced firmly in the English tradition and with a full reed chorus on the Swell.
General specification
- Two 61 note manuals, 1 Expression pedal to Swell- 2nd Expression pedal (optional) to Great and Pedal – 6 thumb pistons to Great/Pedal, Swell and Generals.
- 47 General piston memory banks and 8 departmental memory banks.
- 4 programmable specifications.
- Optional (programmable) pistons to Tutti, Reeds off, CF, Auto Pedal reduce.
- Setter piston, General Cancel piston, Midi Control pistons, 3 VPP (acoustic modelling) pistons.
- Crescendo Pedal Function.
- 6 x 30 watt digital amplifiers with 14 inbuilt speakers.
- Voicing Computer.
Voice specification
Pedal
| Open Diapason | 16 |
| Violone | 16 |
| Sub Bass | 16 |
| Principal | 8 |
| Flute | 8 |
| Fifteenth | 4 |
| Ophicleide | 16 |
| Posaune | 8 |
| Clarion | 4 |
| Swell to Pedal | – |
| Great to Pedal | – |
Great
| Bourdon | 16 |
| Open Diapason I | 8 |
| Open Diapason II | 8 |
| Stopped Diapason | 8 |
| Principal | 4 |
| Harmonic Flute | 4 |
| Quint | 2.2/3 |
| Super Octave | 2 |
| Cornet | III |
| Mixture | Vrks |
| Trumpet | 8 |
| Clarinet | 8 |
| Swell to Great | – |
| Tremulant | – |
Swell
| Geigen Principal | 8 |
| Flauto Traverso | 8 |
| Gedackt | 8 |
| Salicional | 8 |
| Vox Angelica | 8 |
| Principal | 4 |
| Saube Flute | 4 |
| Nazard | 2.2/3 |
| Flageolet | 2 |
| Tierce | 2 |
| Mixture 15.19.22.26 | IVrks |
| Contra Fagotto | 16 |
| Cornopean | 8 |
| Hautboy | 8 |
| Clarion | 4 |
| Tremulant | – |
ALTERNATIVE SPECIFICATIONS
It also includes three other alternative specifications: a sparkling Baroque organ; a Romantic French organ and a classical Dutch Classical organ each with separate sample sets.
Emphasis is on tonal quality with each rank, including the individual mixture ranks, being generated separately. The audio system is also impressive; even in standard internal configuration the organ has 14 speakers over six audio channels that enable the ranks to be divided. A “split-semitone” system is also used to give movement to the sound – just one of many inbuilt features that help produce the character of a pipe organ!
CRAFTSMANSHIP
The Sonata, with it’s additional upper work is particularly suitable for the accompaniment of congregational singing. It is well equipped with the usual couplers and a set of general pistons in addition to the individual departmental pistons.
This is a high quality organ with a rugged oak console that will gives years of durable use especially relevant for church or school use. It will equally look good in the home, that oak slat roll top and detailed cabinet work give an air of refined quality. Even the expression pedal has an oak shoe face to complete the traditional feel of this fine instrument

“When I had my first chance to play the Wyvern Sonata last weekend I was absolutely amazed! The Sonata is just so beautiful to play (and tremendously realistic.) It feels very like playing a well made Continental mechanical-action instrument. Everyone who has seen it cannot praise it enough!”
Mr B Borthwick, Middle Herrington
OPTIONS AND PERSONALISATION
An optional sub bass output is available and a range of compact bass cubes to further enhance the pedal division.
Soon to be released Sonata Deluxe. An enhanced version of the Sonata with the following additions: adjustable music desk, sequencer with brass toe pistons. £11,200 inc vat.
Dimensions
Width: 1280mm
Height: 1160mm
Depth: 5850mm (depth including pedalboard 960mm)
Weight: 134kgs
£12,500
Available in other finishes
